Thermal Gas Mass Flow Meter Advantages
sales01@cxflowmeter.com
The thermal gas mass flow meter is designed according to the principle of thermal diffusion, and the instrument uses the constant temperature
difference method to accurately measure the gas. It has the advantages of small size, high degree of digitization, convenient installation and
accurate measurement.
Technical advantages
1. The gas flow measurement of the real mass flow meter does not require temperature and pressure compensation, and the measurement is
convenient and accurate. available gas
Body weight flow or standard volume flow.
2. The thermal gas flow meter has a wide range ratio, can measure gas with a flow rate as high as 120Nm/s and as low as 0.1Nm/s, and can be
used for gas leak detection.
3. Compared with general measuring equipment, Kunke thermal gas flowmeter has good shock resistance and long service life. The sensor has
no moving parts and pressure sensing parts, and is not affected by vibration on measurement accuracy.
4. Easy installation and maintenance. When site conditions permit, non-stop production, installation and maintenance can be realized.
(need special customization)
5. Digital design. Overall digital circuit measurement, accurate measurement and easy maintenance.
6. Using RS-485 communication or HART communication can realize factory automation and integration.
7. New thermal gas flowmeter: combined hot film probe thermal gas flowmeter
Connection Specifications
1. Thread connection, flange clamping, flange connection: DN10～DN50.
2. Flange installation and flange connection: DN10～DN2000.
3. Plug-in type: DN80～DN2000.
If you want to know more about thermal gas mass flowmeter selection and price, please contact winny: sales01@cxflowmeter.com
