The working principle of magnetic flow meter is through the excitation principle, and the measured medium must have conductivity to ensure the accuracy of measurement.

sales01@cxflowmeter.com



The most important sensing method of the electromagnetic flow meter is through the electrode. During the use of the electrode, the dirt will be attached, which will cause the electromagnetic flowmeter to fail to work normally.



So how can we clean the ditch inside the electromagnetic flow meter?



The magnetic flow meter cleaning method adopts the bullet-shaped electrode that reduces the covering layer, the ultrasonic cleaning method, and the capacitance signal detector to reduce the influence. Common cleaning methods:

Ultrasonic cleaning: High-energy ultrasonic waves are induced on each electrode shaft with an external oscillator and transducer. By selecting the length of the motor shaft and the frequency of the ultrasonic wave, antinodes are generated on the surface of the electrode, so that the local cavitation formed on the electrode of the electromagnetic flowmeter can be deposited.

Mechanical scraper: In this system, each electrode is equipped with a rotary scraper, and the scraper blade is perpendicular to the electrode surface. The shaft of the scraper is driven by an external motor or manually through a hydraulic seal. Can run continuously or intermittently .



Detachable electrode: Detachable electrode adopts mechanical valve and sealing device, and the electrode can be disassembled for external inspection and cleaning.





If you want to know more about key cixi magnetic flowmeter usage range, usage method and quotation, please contact winny:sales01@cxflowmeter.com
